Start here
ASUS SP97 / SP97‑V Motherboard User Manual
This manual covers the ASUS SP97 / SP97‑V motherboard, a Pentium‑class board featuring SiS chipsets, dual AT/ATX power connectors, and a range of expansion slots. It includes sections on hardware installation, BIOS configuration, optional SCSI and audio cards, and software driver installation for Windows, OS/2, and other operating systems.
The document also provides safety notices, FCC compliance information, and detailed troubleshooting guidance, making it a comprehensive reference for system builders and technicians.
ASUS SP97 specifications
| Chipset | SiS5598 (or Si85582) |
|---|---|
| Memory Support | Four 72‑pin SIMM sockets, 4‑64 MB FPM or EDO modules, up to 256 MB total |
| Expansion Slots | 2 × 16‑bit ISA, 3 × 32‑bit PCI, 1 × PCI/ISA shared slot |
| Power Connectors | Dual AT and ATX power connectors on board |
All ASUS SP97 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many ISA and PCI slots does the ASUS SP97 have?
It provides two 16‑bit ISA slots, three 32‑bit PCI slots, and one shared PCI/ISA slot.
How can I restore the BIOS defaults on the SP97 board?
Select the “Load Setup Defaults” option in the BIOS menu to restore factory settings.
How many serial ports are provided on the board?
The board provides two high‑speed UART‑compatible serial ports.
Does the motherboard support both AT and ATX power supplies?
Yes, it includes both AT and ATX power connectors for dual power‑supply compatibility.
How much memory can be installed and what type is required?
Up to four 72‑pin SIMM modules (4‑64 MB each, FPM or EDO) can be installed for a maximum of 256 MB.
What expansion slots are available on the motherboard?
The board provides two 16‑bit ISA slots, three 32‑bit PCI slots, and one shared PCI/ISA slot.
