Key facts
- Brand
- ASUS
- Model
- A8N-VM
- Category
- Motherboard
- Industry
- Computers
- Documents
- 3
- Languages
- ZH · EN
- Last added
- 2012-04-06
Start here
ASUS A8N-VM Motherboard User Manual
This manual covers safety information that must be observed before handling or installing the A8N-VM motherboard, including precautions to avoid electric shock and component damage. It also explains the proper procedures for installing the board, connecting power, and attaching peripherals.
The document details BIOS configuration options, jumper settings, power management features, and boot menu selections. Additional sections describe driver installation, supported hardware components, and troubleshooting tips. This manual is written in Chinese.
ASUS A8N-VM specifications
| Chipset (Northbridge) | NVIDIA GeForce 6150B GPU |
|---|---|
| Chipset (Southbridge) | NVIDIA nForce 430 MCP |
| Front Side Bus | 2000/1600 MT/s |
| Memory Architecture | Dual‑channel DDR, up to 4 GB |
| DIMM Slots | 4 × 184‑pin, up to 4 GB DDR |
| Expansion Slots | 1 × PCI‑Express x16, 1 × PCI‑Express x1, 2 × PCI |
| Graphics | Integrated NVIDIA GeForce 6150B, DVI‑D and RGB outputs |
| Audio | SoundMAX ADI AD1986A 5.1‑channel CODEC |
| IEEE 1394 Ports | 2 × IEEE 1394a |
All ASUS A8N-VM documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How can I access the BIOS settings on the A8N-VM motherboard?
Press the designated key during system start‑up to enter the BIOS menu and adjust the settings as described.
What is the purpose of the JumperFree configuration section?
It explains how to set jumper‑free options for configuring the motherboard without manually moving jumpers.
What actions can void the ASUS product warranty?
The warranty is void if the product is repaired, modified, or altered without ASUS written permission, or if the serial number is defaced or missing.
How do you save BIOS changes before exiting the setup program?
Select the “Exit & Save Changes” option, confirm the prompt, and the changes are written to the CMOS RAM.
What CPU socket does the A8N‑VM CSM motherboard use?
It uses a Socket 939 for AMD Athlon 64FX, Athlon 64 X2, and Athlon 64 processors.
How many PCI Express slots are provided?
The board has one PCI Express x16 slot and one PCI Express x1 slot.
