This manual introduces the features and usage methods of the A8N-VM CSM motherboard.
This manual covers the ASUS A8N-VM CSM motherboard, including safety information, hardware specifications, and installation procedures. It details the chipset, memory architecture, expansion slots, audio, video, and networking features, as well as FCC and Canadian compliance statements.
The guide also explains BIOS configuration, power‑management options, and software support such as the support CD utilities and contact information for technical assistance. It is intended for end users and system builders who need to install, configure, and maintain the motherboard.
| Northbridge | NVIDIA GeForce 6150 GPU |
|---|---|
| Southbridge | NVIDIA nForce 430 MCP |
| Front Side Bus | 2000/1600 MT/s |
| Memory | 4 × 184‑pin DIMM sockets, up to 4 GB, 400/333 MHz DDR |
| Expansion Slots | 1 × PCI Express x16, 1 × PCI Express x1, 2 × PCI |
| Audio Codec | SoundMAX ADI AD1986A 5.1‑channel |
| Network | Built‑in Gigabit MAC with Marvell 88E1111 PHY |
It uses a Socket 939 for AMD Athlon 64FX, Athlon 64 X2, and Athlon 64 processors.
The board has one PCI Express x16 slot and one PCI Express x1 slot.
It includes a SoundMAX ADI AD1986A 5.1‑channel CODEC with jack‑sensing and S/PDIF output.
Disconnect the power cable, unplug all device power cables before connecting signal cables, and avoid short‑circuit hazards such as metal objects near connectors.
