Yamaha mLAN16E Expansion Board Owner's Manual
The Yamaha mLAN16E is an expansion board featuring an mLAN interface designed for music production. It adds two mLAN connectors to compatible devices, such as the Yamaha MOTIF ES synthesizer, facilitating digital network construction based on the IEEE1394 high-performance serial bus protocol.
Read onlineYamaha MLAN16E specifications
| Data Transfer Rate | up to 400Mbps |
|---|---|
| Audio Channel I/Os | Up to 16 audio channel I/Os |
| MIDI Connector I/Os | six MIDI connector I/Os |
| Compatible Devices | MOTIF ES music production synthesizer |
| Recommended Cable Length | 4.5 meters or less |
All Yamaha MLAN16E documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What is the mLAN16E?
The mLAN16E is an expansion board that features an mLAN interface and adds two mLAN connectors to a compatible device.
What software is included with the mLAN16E?
The package includes drivers required to connect the device to a computer and MLAN Graphic Patchbay software.
What operating systems are supported by the software included on the CD-ROM?
The CD-ROM contains software for Windows and Mac OS 9, but it does not include software for Macintosh or Mac OS X.
From: Yamaha i88X/mLAN16E MY16-mLAN Plug-in Effect Installation Guide
What specific precautions must be taken regarding power when installing the mLAN applications?
You must install the software while the power to the mLAN devices is off, then turn them on after the computer displays a message.
From: Yamaha i88X/mLAN16E MY16-mLAN Plug-in Effect Installation Guide
