STMicroelectronics AN2653 Operational Amplifier Stability Compensation Methods Application Note
This document explains operational amplifier stability issues, specifically focusing on the TS507 high precision rail-to-rail amplifier. It details how capacitive loads impact stability and introduces three main compensation methods: out-of-the-loop, in-the-loop, and snubber network techniques. The text provides theoretical overviews and specific application data for the TS507 to help designers avoid oscillations.
Read onlineSTMicroelectronics TS507 specifications
| Gain bandwidth product | 1.9 MHz |
|---|---|
| Input offset voltage | very low |
| Package types | SOT23-5 and SO-8 |
Source: STMicroelectronics AN2653 Operational Amplifier Stability Compensation Methods Application Note
All STMicroelectronics TS507 documents by type
How to use the product for one specific task, with worked examples.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
How does a capacitive load affect stability?
A capacitive load adds a pole to the loop gain, which decreases stability and can cause oscillations.
From: STMicroelectronics AN2653 Operational Amplifier Stability Compensation Methods Application Note
What is the maximum capacitive load value tested for the TS507 in the voltage follower configuration?
The document tests the TS507 with a capacitive load of 550 pF in a voltage follower configuration.
From: STMicroelectronics AN2653 Operational Amplifier Stability Compensation Methods Application Note
What is the maximum supply voltage for the TS507?
The maximum supply voltage (Voc) is 6 V.
From: STMicroelectronics TS507 Operational Amplifier Datasheet
What package options are available for the TS507?
The TS507 is offered in SOT23‑5 and SO‑8 packages.
From: STMicroelectronics TS507 Operational Amplifier Datasheet
