915G-TMGF System Board User Manual
This manual describes the specifications, features, and installation procedures for the 915G‑TMGF system board. It includes safety warnings, power‑up instructions, BIOS setup, and details on supported memory, processors, and peripheral interfaces.
Additional sections cover power‑management functions, wake‑on features, audio and networking options, and a comprehensive troubleshooting guide to help resolve common issues such as serial port problems, memory seating, and BIOS configuration errors.
Intel 915G‑TMGF specifications
| CPU socket | LGA 775 |
|---|---|
| Northbridge chipset | Intel 915G Express |
| Southbridge chipset | Intel 82801FB ICH6 |
| DDR DIMM slots | 4 × 184‑pin DDR DIMM |
| LAN controller (TMGF) | Realtek RTL8110SB Gigabit Ethernet |
| LAN controller (TML) | Realtek RTL8100C 10/100 Ethernet |
| SATA ports | 4 × SATA 1.0 (1.5 Gbps) |
| USB ports | 4 × USB 2.0 |
All Intel 915G‑TMGF documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What type of CPU socket does the motherboard use?
The board uses an LGA 775 socket for the processor.
How many DDR memory slots are available and what is the maximum memory?
There are four 184‑pin DDR DIMM slots supporting up to 4 GB of RAM.
What should be done before removing the system chassis cover?
The power cord must be unplugged before removing the chassis cover.
How should I safely replace the battery on the system board?
Replacing the battery incorrectly can cause an explosion; only replace it with the same or an equivalent type recommended by the manufacturer and follow the disposal instructions.
What is the required 5VSB power source for the Clear CMOS jumper?
The 5VSB power source of the power supply must support at least 720 mA.
From: Intel 915G‑TMGF / 915GV‑TML / 915GL‑TML System Board User Manual
What type of LAN port does the 915GV‑TML/915GL‑TML version have?
It has a 10/100 Mbps Ethernet LAN port.
From: Intel 915G‑TMGF / 915GV‑TML / 915GL‑TML System Board User Manual
