Key facts
- Brand
- Intel
- Model
- D850EMD2
- Category
- Motherboard
- Industry
- Computers
- Documents
- 3
- Languages
- ZH · EN
- Last added
- 2012-03-22
Start here
Intel D850EMD2 D850EMV2 Selection Guide
The guide covers the functional overview of the D850EMD2 and D850EMV2 motherboards, including supported CPUs, memory types, expansion slots, and onboard peripherals. It also details compliance information and regulatory statements for North America and Canada.
Installation procedures, BIOS update methods, and setup utility navigation are described step‑by‑step, with diagrams for component placement, connector locations, and configuration options such as PCI, AGP, IDE, USB, and LAN settings.
Intel D850EMD2 specifications
| Form factor (D850EMD2) | microATX |
|---|---|
| Front Side Bus (D850EMD2) | 400 MHz |
| Front Side Bus (D850EMV2) | 533 MHz |
| Memory speed | PC800‑40 |
| Memory speed | PC800‑45 |
All Intel D850EMD2 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How can I update the BIOS on the D850EMD2/D850EMV2 motherboard?
Use the Intel Express BIOS Update utility provided in the manual.
Where are the boot device priority settings located?
Boot device priority is configured in the BIOS under the Boot Configuration section.
What processors are supported by the D850EMD2 and D850EMV2 boards?
They support Intel Pentium 4 processors in an mPGA478 socket with either a 533 MHz or 400 MHz front‑side bus.
From: Intel D850EMD2 and D850EMV2 Desktop Board Product Guide
How many USB ports are available on these desktop boards?
Each board provides up to five USB 2.0 ports – two on the rear panel, two on the front panel, and one optional port via the CNR connector.
From: Intel D850EMD2 and D850EMV2 Desktop Board Product Guide
