Intel D815EEA2/D815EPEA2/D815EFV/D815EPFV Desktop Board Product Guide
This product guide describes the Intel D815EEA2, D815EPEA2, D815EFV and D815EPFV desktop boards, their chipset options, supported processors, memory configurations and I/O interfaces. It includes detailed tables of board differences, feature summaries and hardware specifications.
The manual provides step‑by‑step installation and replacement procedures, BIOS update instructions, setup program navigation, safety and regulatory compliance notes, and troubleshooting information such as beep codes and error messages.
Intel 815EP specifications
| BIOS identifier | EA81520A.86A |
|---|---|
| Speaker impedance | 47 Ω |
| Form factor | MicroATX |
Source: Intel D815EFV/D815EPFV Desktop Board Technical Product Specification
All Intel 815EP documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What does the BIOS beep code pattern of one long tone followed by two short tones indicate?
It indicates a video configuration failure, such as a faulty video card or no card installed.
From: Intel D815EFV/D815EPFV Desktop Board Technical Product Specification
How many PCI slots does the D815EEA2 board provide?
The D815EEA2 board provides five PCI add‑in card connectors.
From: Intel D815EEA2/D815EPEA2/D815EFV/D815EPFV Desktop Board Product Guide
What type of memory is supported?
It supports PC133 memory modules.
From: An Intel 815EP chipset based Socket30 mainboard Manual
Which chipset is used on this mainboard?
The board is based on the Intel 815EP chipset.
From: An Intel 815EP chipset based Socket30 mainboard Manual
