Bosch AutoDome 100 Manuals

ManualLib has 2 documents for the Bosch AutoDome 100 (Other): 2 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 2

Key facts

Brand
Bosch
Model
AutoDome 100
Category
Other
Industry
Industrial
Documents
2
Languages
EN · ZH
Last added
2011-10-01

Start here

Bosch AUTODOME 7100i NDP-7602-Z40 User Manual

Bosch AUTODOME 7100i NDP-7602-Z40 User Manual

User Manual 80 pages · 686 KB · EN

This user manual covers the Bosch AUTODOME 7100i, including models NDP-7602-Z40, NDP-7602-Z40L, and NDP-7604-Z12L. It explains browser connection, system requirements, and initial access using the Project Assistant app or a web browser.

The manual describes the Live, Playback, Configuration, and Dashboard pages, then covers camera settings, recording, alarms, network configuration, service, troubleshooting, hardware reset, status codes, AUX commands, and support services. It was published by Bosch Security Systems B.V. in December 2022.

Read online

Bosch AutoDome 100 specifications

Maximum RCP+ connections128
Default IP address192.168.0.1
Maximum Ethernet cable length100 m
Power supply24 VAC or 36 VDC
Supported operating systemWindows 10 or later
Supported web browsersGoogle Chrome, Microsoft Edge, or Mozilla Firefox
Recommended SD cardindustrial SD cards from Western Digital

Source: Bosch AUTODOME 7100i NDP-7602-Z40 User Manual

All Bosch AutoDome 100 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the default IP address of the device?

The default IP address is 192.168.0.1.

From: Bosch AUTODOME 7100i NDP-7602-Z40 User Manual

How many RCP+ connections can the camera handle?

It can handle a maximum of 128 RCP+ connections.

From: Bosch AUTODOME 7100i NDP-7602-Z40 User Manual

What video formats does the AutoDome 100 support?

It supports both PAL and NTSC formats with a video output of 1.0 Vp‑p into a 75 Ω load.

From: Bosch AutoDome 100 Fixed Dome Camera System Guide

How can the system be upgraded from analog to IP?

By swapping the interchangeable modules—such as the CPU, camera and communication module—the system can be converted from analog to IP without replacing the whole dome.

From: Bosch AutoDome 100 Fixed Dome Camera System Guide
