Start here
Analog Devices ADuC841/ADuC842/ADuC843 User Manual
The ADuC841, ADuC842, and ADuC843 are 12‑bit microcontroller families that integrate a high‑performance ADC, dual DAC (except ADuC843), and a single‑cycle 20 MIPS 8052 core on a single chip. They are pin‑compatible upgrades of the ADuC812/ADuC831 series and are offered in 52‑lead PQFP and chip‑scale packages.
This manual contains functional descriptions, pin configurations, electrical specifications, memory organization, peripheral registers, timing diagrams, development tool information, and ordering guides. It also includes detailed ADC and DAC specifications, power‑supply requirements, and hardware design considerations.
Analog Devices ADUC842 specifications
| ADC Resolution | 12-Bit |
|---|---|
| Flash Memory Size | 62 kB |
| DATAFLASH/EE Capacity | 4 kB |
Source: Analog Devices ADuC841/ADuC842/ADuC843 Anomaly Sheet
All Analog Devices ADUC842 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the workaround for UART Mode 0 on these devices?
UART Mode 0 is nonfunctional on the ADuC841/ADuC842/ADuC843, and there are no workarounds provided.
How should code handle interrupts during DATAFLASH/EE read or write operations?
All interrupts must be disabled prior to a read or write operation by setting the EA bit to 0.
What is the workaround for UART Mode 0 operation?
UART Mode 0 is nonfunctional on these devices, and there are no workarounds provided.
How should code handle interrupts during DATAFLASH/EE read or write?
All interrupts must be disabled prior to a read or write operation by setting the EA bit to 0.
Is the ADuC842 pin compatible with previous models?
Yes, it is pin compatible with the ADuC812 and ADuC832.
What is the maximum operating frequency of the ADuC842?
The maximum operating frequency is 16.777MHz.
