Start here
Yamaha AX-10 Owner's Manual
This document is the owner's manual for the Yamaha AX-10 Natural Sound Stereo Integrated Amplifier. It details the supplied accessories, including a remote control transmitter and AA batteries, and provides safety cautions regarding installation in cool, dry places away from heat sources or moisture.
The guide covers system connections for various audio components such as CD players, turntables, and tape decks, explaining how to use the SPEAKERS terminals and AC OUTLETS. It also includes step-by-step instructions for operating the amplifier, selecting input sources like TUNER, TAPE 1/2, PHONO, and AUX, and adjusting volume, bass, treble, and balance controls.
Yamaha AX-10 specifications
| Frequency Response (AX10) | 65Hz-20kHz |
|---|---|
| Nominal Impedance | 8Q |
| Sensitivity (AX12) | 97dB SPL (1W, 1m) |
Source: Yamaha AX10/AX12/AX15/AX12M/AX15M/AX15W Speaker System Owner's Manual
All Yamaha AX-10 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What type of plugs should be used for Neutrik NL4FC connectors?
You must use proper speaker cable and specifically Neutrik NL4FC plugs.
From: Yamaha AX10/AX12/AX15/AX12M/AX15M/AX15W Speaker System Owner's Manual
What is the maximum height allowed for the TS-80/TS-90 speaker stands?
The stand should be used at a maximum height of 140 cm.
From: Yamaha AX10/AX12/AX15/AX12M/AX15M/AX15W Speaker System Owner's Manual
What size batteries are required for the remote control?
The remote control requires two AA size batteries.
What is the maximum power that can be connected to the switched AC outlets?
The switched AC outlets can supply a maximum of 100 watts.
