Start here
Tektronix VM700T PAL Video Measurement System User Manual
The Tektronix VM700T is a video measurement system designed to monitor and measure baseband video and audio signals. It supports various standards including CCIR Rep.624-1, Rec.567, and Rec.569. The system features both automatic and manual operation modes, allowing engineers of all skill levels to perform measurements easily. This manual is written in Chinese.
Read onlineTektronix VM700T specifications
| Temperature Range | 0～50℃ |
|---|---|
| Preheat Time | 20 minutes |
| Input Signal Level (Peak-to-Peak) | 1V |
| Unweighted SNR Requirement | 60dB |
Source: Tektronix VM700T PAL Video Measurement System User Manual
All Tektronix VM700T documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Can the VM700T be remotely controlled?
Yes, it can be remotely operated via RS-232C using protocols like FTP and TELNET.
From: Tektronix VM700T PAL Video Measurement System User Manual
What is the VM700T used for?
The VM700T is used for monitoring and measuring baseband video and audio signals.
From: Tektronix VM700T PAL Video Measurement System User Manual
What temperature range can the VM700T operate in?
The instrument is rated for temperatures from 0 °C to 50 °C.
How can the VM700T be controlled remotely?
It can be controlled via RS‑232C using Tektronix’s full‑document remote language, supporting FTP and TELNET protocols.
