Start here
Tektronix MDO3000 Mixed Domain Oscilloscope User Manual
This manual covers safety information, installation steps, and operating procedures for the MDO3000 mixed‑domain oscilloscope. It includes guidance on connecting probes, configuring acquisition modes, and using advanced features such as MagniVu, FFT, and arbitrary function generation.
The document also details compliance with EMC, safety, and environmental standards, warranty terms, and provides extensive technical specifications and appendices for probe compensation, firmware upgrades, and network connectivity.
Tektronix MDO3000 Series specifications
| Analog bandwidth (full bandwidth) | 1.00 GHz |
|---|---|
| Analog bandwidth (50 Ω input) | 100 MHz |
| DC gain accuracy (1 mV/div) | ±2.5 % |
| Vertical resolution (DC gain) | ±2.5 % |
Source: Tektronix MDO3000 Mixed Domain Oscilloscope User Manual
All Tektronix MDO3000 Series documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
How long is the warranty for the MDO3000 oscilloscope?
The instrument is covered for three (3) years from the date of purchase from an authorized Tektronix distributor.
From: Tektronix MDO3000 Mixed Domain Oscilloscope User Manual
What is the warranty period for the probes (TPP0250, TPP0500B, TPP1000)?
The probes are covered for one (1) year from the date of purchase from an authorized Tektronix distributor.
From: Tektronix MDO3000 Mixed Domain Oscilloscope User Manual
What are the allowed operating temperature limits?
The device operates safely from –10 °C to +55 °C.
From: Tektronix MDO3000 Series Oscilloscopes Installation and Safety Instructions
