Start here
Tektronix TPS2000 Series Digital Storage Oscilloscope User Manual
The Tektronix TPS2000 Series Digital Storage Oscilloscope User Manual covers essential topics including general safety, compliance information, and installation procedures. It details how to perform floating measurements, install probes, and conduct functional checks to ensure proper operation before use.
The guide further explains basic operations such as using the menu system, vertical and horizontal controls, and trigger settings. It includes sections on acquiring signals, scaling waveforms, performing measurements, and utilizing mathematical functions like FFT analysis. This manual is written in Chinese.
Tektronix TPS2000 Series specifications
| Sampling Rate (Typical) | 180 waveforms per second per channel |
|---|---|
| Input Impedance (DC Coupled) | 1 MΩ ±2% in parallel with 20 pF ±3 pF |
| Input Coupling | DC, AC, or Ground |
Source: Tektronix TPS2000 Series Digital Storage Oscilloscope User Manual
All Tektronix TPS2000 Series documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the typical sampling rate for the TPS2000 series?
The typical sampling rate is up to 180 waveforms per second per channel in sample mode.
From: Tektronix TPS2000 Series Digital Storage Oscilloscope User Manual
What are the input coupling options?
The oscilloscope supports DC, AC, or Ground coupling for inputs.
From: Tektronix TPS2000 Series Digital Storage Oscilloscope User Manual
