Start here
Tektronix 4200A-SCS Parameter Analyzer Product Data Sheet
The Tektronix 4200A-SCS is a customizable, fully integrated parameter analyzer designed for semiconductor, material, and process development. It supports simultaneous viewing of current-voltage (I-V), capacitance-voltage (C-V), and ultrafast pulsed I-V characteristics. The instrument is equipped with Clarius software to provide advanced test definition, parameter analysis, plotting, and automation capabilities. This manual is written in Chinese.
Read onlineAll Tektronix 4200A-SCS documents by type
Questions answered in these manuals
What is the maximum voltage and current rating for the high-power SMU module?
The high-power Source Measurement Unit (SMU) has a range of ±1 A at ±210 V.
From: Tektronix 4200A-SCS Parameter Analyzer Product Data Sheet
What is the frequency range for AC impedance measurement in the Capacitance Voltage Unit?
The unit supports an AC impedance measurement frequency range from 1 kHz to 10 MHz.
From: Tektronix 4200A-SCS Parameter Analyzer Product Data Sheet
What is the maximum voltage and current rating for the standard medium-power SMU?
The standard medium-power source measurement unit (SMU) provides a range of ±210 V at 100 mA.
From: Tektronix 4200A-SCS Parameter Analyzer Product Data Sheet
How does the optional remote front-end amplifier module affect current measurement resolution?
When configured with the optional 4200-PA module, the SMU can measure currents down to a resolution of 10 aA.
From: Tektronix 4200A-SCS Parameter Analyzer Product Data Sheet
