Start here
Tektronix TLA7000 Series Master Manual
This manual describes the TLA7000 series host units, including portable (TLA7012) and desktop (TLA7016) models, their controllers, and optional accessories. It covers system architecture, hardware configuration, and software interfaces such as Windows XP, .NET and COM/DCOM.
Detailed sections provide physical dimensions, environmental limits, power consumption, channel capacity, safety certifications, and connection options for external oscilloscopes, USB, LAN, GPIB and other interfaces. This manual is written in Chinese.
Tektronix TLA7000 series specifications
| Maximum power consumption (TLA7012) | 750 W |
|---|---|
| Maximum power consumption (TLA7016) | 1.450 W |
| Maximum analysis channels (TLA7016) | 6,528 |
| Operating temperature range | +5°C to +45°C |
| Operating altitude range | -1,000 ft to 10,000 ft |
| Safety certifications | UL3111-1, CSA1010.1, EN61010-1, IEC61010-1 |
All Tektronix TLA7000 series documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum power consumption of the TLA7012?
The TLA7012 consumes up to 750 W of power.
How many analysis channels does the TLA7016 support?
The TLA7016 supports up to 6,528 analysis channels.
What is the maximum number of logic analyzer channels supported?
The TLA7000 Series supports up to 6,528 logic analyzer channels.
From: Tektronix TLA7000 Series Logic Analyzer Host User Manual
Can the TLA7012 and TLA7016 hosts be used together?
Yes, they can be configured as a master or expansion host using TekLink cables.
From: Tektronix TLA7000 Series Logic Analyzer Host User Manual
Can a single probe capture both analog and digital signals?
Yes, the TLA series probe can acquire both analog and digital measurements with one probe.
From: Tektronix TLA5000/TLA7000 Series Logic Analyzer Selection Guide
