Sharp PN-V601 LCD Monitor Operation Guide
This operation guide explains how to use the Sharp PN‑V601 LCD monitor. It covers basic operation, remote‑control mode, menu navigation, screen‑size adjustments, initialization, and troubleshooting. Detailed sections describe controlling the monitor via PC using RS‑232C or LAN, as well as the full list of specifications.
The manual also includes information on optional expansion boards, safety cautions, and how to reset settings to factory defaults. Users can adjust brightness, contrast, color mode, and other picture settings through the on‑screen menu or the remote control unit.
Sharp PN-V601 specifications
| Model | PN-V601 |
|---|---|
| Screen size | 60" (152.4 cm) diagonal |
| Maximum resolution | 1366 × 768 pixels |
| Maximum colors | ≈ 16.77 M colors |
| Pixel pitch | 0.973 mm (H) × 0.973 mm (V) |
| Viewing angle | 176° right/left/up/down |
| Contrast ratio | ≥ 10 |
| Active area | 52‑5/8 × 29‑7/16 in (1328.8 × 747.1 mm) |
| Computer input signal | Digital DVI 1.0, Analog RGB (0.7 Vp‑p) |
| Sync signal | H/V separate (TTL), sync‑on‑green, composite sync |
| Video color system | NTSC (3.58 MHz) |
All Sharp PN-V601 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do you reset menu settings to the factory defaults?
Select the RESET option for the desired menu (e.g., SCREEN, PICTURE, AUDIO) and confirm; the values return to factory presets.
How can I mute the audio?
Press the MUTE button on the monitor to mute the sound; press it again to restore the previous volume level.
How do I change the input source?
Press the INPUT button and select the desired input (e.g., HDMI, DVI‑D, PC‑D‑sub) from the menu.
