honeywell TB8220U Commercial VisionPRO Programmable Thermostat
This user guide provides step‑by‑step instructions for getting started with the Honeywell Hyperion 1300g handheld linear scanner, including unpacking, connecting via USB, keyboard wedge, RS‑232 or RS‑485, and basic operation. It also details menu navigation, security settings, and how to reset the scanner to its standard defaults.
The manual covers advanced programming of the interface, input/output configuration, data editing, formatting, and a full list of supported symbologies such as Code 39, Code 128, UPC, EAN, and many others. Utilities, serial programming commands, and a programming chart are included for technicians and developers who need to customize the scanner for specific applications.
Honeywell TB8220U specifications
| Heating Voltage | 20‑30 Vac |
|---|---|
| Cooling Voltage | 20‑30 Vac |
| Fan Voltage | 20‑30 Vac |
| Economizer/TOD Voltage | 20‑30 Vac |
| Heating Temperature Setting Range | 40°F to 90°F (4.5°C to 32°C) |
| Cooling Temperature Setting Range | 50°F to 99°F (10°C to 37°C) |
| Operating Ambient Temperature | 0°F to 120°F (-18°C to 49°C) |
| Shipping Temperature | -30°F to 150°F (-34.4°C to 65.6°C) |
| Operating Relative Humidity (Non‑condensing) | 5% to 90% |
| Thermostat Dimensions | 3‑3/4 in. high x 6 in. wide x 1‑3/8 in. deep |
Source: Honeywell TB8220U Commercial VisionPRO Programmable Thermostat User Manual
All Honeywell TB8220U documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What temperature ranges can be programmed for heating and cooling?
Heating can be set from 40 °F to 90 °F, and cooling from 50 °F to 99 °F.
From: Honeywell TB8220U Commercial VisionPRO Programmable Thermostat User Manual
How do I reset the scanner to its default settings?
Use the "Resetting the Standard Product Defaults" command found in Chapter 8 of the guide.
From: honeywell TB8220U Commercial VisionPRO Programmable Thermostat
