Start here
Haier Q-B-J-130 Solar Water Heater User Manual
This manual provides step‑by‑step installation instructions, safety precautions, and operating guidelines for the Haier Q‑B‑J‑130 solar water heater. It covers proper placement, pipe routing, controller connection, and required insulation to ensure efficient and safe operation.
The document also lists technical specifications such as tank capacity, material, dimensions, and warranty information, and includes a troubleshooting section for common issues like low water temperature or vacuum tube failure. This manual is written in Chinese.
Haier Q-B-J-1-130 specifications
| Tank Capacity | 130 L |
|---|---|
| Tank Material | SUS304 stainless steel |
| Dimensions (L × W) | 1917 mm × 1135 mm |
| Rated Pressure | 0.05 MPa |
All Haier Q-B-J-1-130 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Haier Q-B-J-130 Solar Water Heater User Manual 8 p
- Haier Q-B-J-1-130/1.79/0.05-W/Z Water Heater User Manual 8 p
- Haier Sun water heater Q-B-J-1-130/1.79/0.05-W/E Manual
- Haier Sun water heater Q-B-J-1-130/1.79/0.05-D/H Q-B-J-1-150/2.07/0.05-D/H series Manual 8 p
- Haier Sun water heater Q-B-J-1-130/1.79/0.05-D/H Q-B-J-1-150/2.07/0.05-D/H Manual 2 p
Questions answered in these manuals
How should the overflow pipe be installed?
The overflow pipe must be positioned downward, fixed securely, and its outlet should be level with the drainage pipe, maintaining a clearance of about 15 cm.
What material is used for the water tank interior?
The tank interior is made of SUS304 stainless steel, which is lead‑free and suitable for food contact.
How do I manually fill the tank when the controller fails?
Press the manual fill valve, open the overflow pipe, and fill the tank until water flows out of the overflow.
From: Haier Sun water heater Q-B-J-1-130/1.79/0.05-D/H Q-B-J-1-150/2.07/0.05-D/H series Manual
Can the hot water from the solar water heater be used as drinking water?
No, the manual states that the hot water should not be used directly as drinking water.
From: Haier Sun water heater Q-B-J-1-130/1.79/0.05-D/H Q-B-J-1-150/2.07/0.05-D/H Manual
What is the recommended installation orientation for the solar water heater?
The heater should face south with a 10° east or 15° west offset.
From: Haier Sun water heater Q-B-J-1-130/1.79/0.05-D/H Q-B-J-1-150/2.07/0.05-D/H Manual
