Haier CXW-219 Manuals

Key facts

Brand: Haier
Model: CXW-219
Category: Air Cleaners Purifiers
Industry: Appliances
Documents: 12
Languages: ZH
Last added: 2012-04-09

Start here

Haier CXW-219-D66G/D66GM/D66GL Range Hood User Manual

User Manual 9 pages · 4.7 MB · ZH

This manual begins with safety precautions, warning symbols, and general usage notes for the CXW‑219‑D66G/D66GM/D66GL range hood. It explains the function of each component, such as the motor, fan wheel, oil cup, and filter, and outlines the required tools and steps for proper installation.

Subsequent sections cover operation controls (power, lighting, speed, delay, clock), cleaning and maintenance procedures, troubleshooting of common faults, and warranty information. Technical data and a parts list are also included for reference. This manual is written in Chinese.

Read online

Haier CXW-219 specifications

Rated Voltage	220 V
Rated Frequency	50 Hz
Motor Input Power	219 W
Maximum Noise Level	54 dB / 52 dB
Maximum Wind Pressure	> 320 Pa
Air Duct Diameter	160 mm
Power Cord Length	1500 mm
Net Weight	23 kg

Source: Haier CXW-219-DT90 CXW-219-DT901 CXW-219-JT90G CXW-219-JT901A CXW-219-J66GS CXW-2 19-J66GS(T1) CXW-219-JT30A CXW-219-JT30B CXW-219-JT30C CXW-219-JT30(SN) CXW-219-JT10 CXW-219-JT10A range hood Manual

All Haier CXW-219 documents by type

User Manual 11

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Other documents 1

Haier CXW-219-D66T/DA30T household range hood Manual

Questions answered in these manuals

What should be done before cleaning the range hood?

Unplug the power plug before cleaning or maintaining the hood.

From: Haier CXW-219-DT90 CXW-219-DT901 CXW-219-JT90G CXW-219-JT901A CXW-219-J66GS CXW-2 19-J66GS(T1) CXW-219-JT30A CXW-219-JT30B CXW-219-JT30C CXW-219-JT30(SN) CXW-219-JT10 CXW-219-JT10A range hood Manual

How often should the fan wheel be cleaned?

The fan wheel should be cleaned every three months.

From: Haier CXW-219-DT90 CXW-219-DT901 CXW-219-JT90G CXW-219-JT901A CXW-219-J66GS CXW-2 19-J66GS(T1) CXW-219-JT30A CXW-219-JT30B CXW-219-JT30C CXW-219-JT30(SN) CXW-219-JT10 CXW-219-JT10A range hood Manual

How do I clean or remove the oil cup?

First disconnect the power plug, then unscrew the oil‑cup retaining screw and take out the oil cup for cleaning.

From: Haier CXW-219-D68(S) Range Hood User Manual

What happens if the motor overheats?

The motor has a thermal protection device that automatically cuts power when the temperature reaches the protection limit; stop the unit and check for blockages before restarting.
