Key facts
- Brand
- Haier
- Model
- ES60H-MG
- Category
- Water heater
- Industry
- Appliances
- Documents
- 2
- Languages
- ZH
- Last added
- 2012-04-01
Start here
Haier ES40H-MG(ME) / ES50H-MG(ME) / ES60H-MG(ME) / ES80H-MG(ME) Water Heater User Manual
This manual begins with safety precautions, explaining the meaning of warning symbols and the special safety indicator that alerts you when the grounding line is live. It also details the required independent 220 V/50 Hz power supply, proper grounding, and installation requirements such as wall strength and pipe connections.
The second part covers operation, including how to set temperature, select heating modes, and use the remote control. It provides cleaning and maintenance procedures, recommended service intervals, and troubleshooting FAQs such as what to do when the safety indicator lights up. This manual is written in Chinese.
Haier ES60H-MG specifications
| Capacity | 40 L / 50 L / 60 L / 80 L |
|---|---|
| Power | 2000 W |
| Voltage | 220 V / 50 Hz |
| Water Pressure Range | 0.05 MPa – 0.8 MPa |
| Dimensions | 200 mm × 200 mm × 200 mm (approx.) |
Source: Haier ES40H-MG(ME) / ES50H-MG(ME) / ES60H-MG(ME) / ES80H-MG(ME) Water Heater User Manual
All Haier ES60H-MG documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the recommended water pressure for installation?
The inlet water pressure must be at least 0.05 MPa and must not exceed 0.8 MPa.
From: Haier ES40H-MG(ME) / ES50H-MG(ME) / ES60H-MG(ME) / ES80H-MG(ME) Water Heater User Manual
Can the water heater be mounted on a non‑load‑bearing wall?
No, the wall must be solid and able to support four times the weight of the fully filled heater.
From: Haier ES40H-MG(ME) / ES50H-MG(ME) / ES60H-MG(ME) / ES80H-MG(ME) Water Heater User Manual
What steps are required before the first use?
Open the cold‑water inlet valve, set the mixing valve to the maximum hot‑water position, and run water until it flows continuously to fill the tank before powering on the heater.
