Key facts
- Brand
- Haier
- Model
- BCD-550
- Industry
- Appliances
- Documents
- 3
- Languages
- ZH
- Last added
- 2012-03-19
Start here
Haier BCD-550WA/555WA Refrigerator User Manual
This manual covers safety precautions, installation requirements, and an overview of the refrigerator’s features such as variable‑frequency compression, ice‑making, and the 007 temperature zone. It explains how to properly place the unit, adjust the door alignment, and connect the appliance to a 220 V/50 Hz power source.
Detailed sections guide users through the fresh‑food compartment, freezer compartment, defrosting, cleaning, and shutdown procedures. The FAQ addresses common concerns, and the after‑sales service section provides warranty and contact information. Technical data and wiring diagrams are included at the end of the document. This manual is written in Chinese.
Haier BCD-550 specifications
| Power Supply | 220V/50Hz AC |
|---|---|
| Cooling System | Full‑air‑cool, R‑134a‑free |
| Ice Maker | Automatic ice, crushed ice and cold water |
| Door Type | Inverter double‑door (对开门) |
All Haier BCD-550 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
Is it safe to store gasoline or other flammable liquids near the refrigerator?
No, flammable substances such as gasoline must not be stored or used near the refrigerator to avoid fire hazards.
How can I adjust the refrigerator door alignment?
Insert a flat wrench into the adjustment screw on the left or right side and turn it according to the arrow direction until both doors close evenly.
What should I do before using the refrigerator?
Read the manual carefully before first use and keep it for future reference.
What voltage does the refrigerator require?
It must be connected to a 220 V / 50 Hz AC supply; if the voltage fluctuates beyond 187‑242 V, a stabilizer over 750 W is recommended.
What is the total effective volume of the BCD-550WB refrigerator?
The total effective volume is 541 L.
Which refrigerant is used in the BCD-550/551/552WB series?
The refrigerators use R134a refrigerant.
