DELL 1409X Manuals

ManualLib has 5 documents for the DELL 1409X: 5 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 5

Key facts

Brand
DELL
Model
1409X
Industry
Electronics
Documents
5
Languages
ZH · EN
Last added
2023-11-03

Start here

Dell 1409X Projector User's Guide

Dell 1409X Projector User's Guide

User Manual 52 pages · 4 MB · EN

This manual covers the setup and operation of the Dell 1409X projector. It details the package contents, safety instructions, and how to connect the projector to various devices such as computers, DVD players, and other video sources using VGA, DVI-D, S-video, Composite, Component, and HDMI cables. The guide also explains how to use the control panel and remote control to adjust settings like picture, display, and language.

Read online

DELL 1409X specifications

Brightness2500 ANSI lumens (maximum)
Contrast ratio1900:1 typical (full on/full off)
Pixel count1024 x 768 (XGA)
Display colors16.7 million colors
Projection screen size22.89–302.8 inches diagonal
Projection distance3.3–39.4 ft (1.0–12 m)
Power consumption256 W in full power mode; 216 W in ECO mode
AudioOne 8 W RMS speaker
Weight4.95 lb (2.25 kg)
Lamp165–200 W user-replaceable lamp; up to 3000 hours (up to 4000 hours in ECO mode)
Operating temperature5°C to 35°C (41°F to 95°F)

Source: Dell 1409X Projector User Manual

All DELL 1409X documents by type

User Manual 5

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the brightness of the Dell 1409X projector?

The maximum brightness is 2500 ANSI lumens.

From: Dell 1409X Projector User Manual

What are the RS232 connection settings?

Use a baud rate of 19200, 8 data bits, no parity, and 1 stop bit.

From: Dell 1409X Projector User Manual

What are the operating temperature requirements?

The projector must operate between ambient temperatures of 5°C to 35°C.

From: Dell 1409X Projector User's Guide

How do I adjust the projected image size?

You can adjust the image size using the Zoom tab and Focus ring on the control panel.

From: Dell 1409X Projector User's Guide

What is the maximum brightness of the Dell 1409X projector?

The projector provides up to 2500 ANSI lumens of brightness.

From: Dell 1409X Projector User Manual

How long does the lamp last in ECO mode?

In ECO mode the lamp can last up to 4000 hours.

From: Dell 1409X Projector User Manual
