This manual describes the features and characteristics of the ISMH and ISMV series servo motors and the IS500 series servo motor controllers.
This manual covers the ISMH and ISMV series permanent‑magnet synchronous servo motors and their matching 1S500 series servo drives. It defines terminology, safety symbols, handling precautions, and the required steps for trial runs, installation, wiring, and adjustments.
The document also includes detailed specifications, mechanical dimensions, cable part numbers, communication functions, and a warranty agreement. It is intended for engineers and technicians who install, commission, and maintain these servo systems in industrial automation applications. This manual is written in Chinese.
| Nominal speed (Vn) – ISMH1 | 3000 rpm |
|---|---|
| Maximum speed (Vmax) – ISMH1 | 6000 rpm |
| Nominal speed (Vn) – ISMV1 | 3000 rpm |
| Maximum speed (Vmax) – ISMV1 | 3000 rpm |
Perform a no‑load trial run with the motor not connected to the drive shaft to prevent accidents.
Wait at least five minutes after power‑off before touching any terminals.
Do not connect three‑phase power to the U, V, W output terminals of the servo drive.
