Key facts
- Brand
- Yamaha
- Model
- XS250
- Category
- Industrial Supply
- Industry
- Industrial
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2012-06-11
Start here
Yamaha XS350/XS250 Power Amplifier Owner's Manual
This manual provides instructions for the Yamaha XS350 and XS250 series power amplifiers, covering controls, functions, and safety precautions. It details the front and rear panel features, including input/output terminals, volume controls, and operating modes such as STEREO, BRIDGE, and PARALLEL.
Read onlineYamaha XS250 specifications
| High‑pass filter adjustable range | 25 Hz – 150 Hz |
|---|---|
| Signal level indicator threshold | 2 Vrms |
| Clip detection threshold | Distortion >12 % |
| Minimum speaker impedance (bridge) | 8 Ω |
All Yamaha XS250 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I adjust the high pass filter frequency?
You can adjust the cut-off frequencies in the range of 25 Hz to 150 Hz when the LOW CUT filter is selected.
What happens when the PROTECTION indicator lights up?
The speaker system is disconnected from the amplifier outputs and no sound is output from the speakers.
How should the power cord be connected safely?
Connect the power cord to the AC inlet described in the manual and avoid placing heavy objects on the cord to prevent fire or electric shock.
How can the high‑pass filter be set?
Select the LOW CUT position and rotate the frequency knob to adjust the cutoff frequency between 25 Hz and 150 Hz.
