Key facts
- Brand
- NXP
- Model
- BT136X-800
- Category
- Other Electronics
- Documents
- 2
- Languages
- ZH · EN
- Last added
- 2014-05-21
Start here
NXP BT136X-800E 4Q Triac Product Data Sheet
Datasheet 14 pages · 207 KB · ZH
The document describes the NXP BT136X-800E 4Q, a planar passivated sensitive gate triac housed in a SOT186A "full pack" plastic package. It is designed for general purpose bidirectional switching and phase control applications. This manual is written in Chinese.
Read onlineAll NXP BT136X-800 documents by type
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum repetitive peak off-state voltage for this triac?
The device has a maximum repetitive peak off-state voltage of 800 V.
What are the minimum and maximum storage temperatures for this component?
The storage temperature ranges from a minimum of -40 to a maximum of 150 °C.
What is the maximum repetitive peak off-state voltage for this triac?
The device has a maximum repetitive peak off-state voltage of 800 V.
What is the maximum non-repetitive peak on-state current for a pulse width of 20 ms?
The device supports a maximum non-repetitive peak on-state current of 25 A for a 20 ms pulse.
