Key facts
- Brand
- NXP
- Model
- ACTT8-800C0
- Documents
- 2
- Languages
- EN
- Last added
- 2014-05-16
Start here
NXP ACTT8-800C0T Thyristor
Datasheet 15 pages · 221 KB · EN
The NXP ACTT8-800COT is an AC Thyristor Triac power switch housed in a SOT78 (TO-220AB) plastic package. It features self-protective clamping capabilities against low and high energy transients, allowing it to commutate full RMS current at a maximum junction temperature of 150 °C without a snubber. This device is designed for applications requiring high junction operating temperature capability.
Read onlineNXP ACTT8-800C0 specifications
| Repetitive peak off-state voltage | 800 V |
|---|---|
| Maximum junction temperature | 150 °C |
| Package type | SOT78 (TO-220AB) |
Source: NXP ACTT8-800C0T Thyristor
All NXP ACTT8-800C0 documents by type
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Does this triac require a snubber?
No, it can commutate the full RMS current at the maximum rated junction temperature without the aid of a snubber.
What is the maximum junction operating temperature?
The maximum rated junction temperature is 150 °C.
