Nihon Inter Electronics EC10QS06 Bridge Rectifier Datasheet
This document is a technical datasheet for the EC10QS06, a miniature size surface mount device (SMD) bridge rectifier manufactured by Nihon Inter Electronics Corporation. Key features include low forward voltage drop, high surge capability, and availability in 30V to 100V types.
The datasheet provides maximum ratings such as a repetitive peak reverse voltage of 60V and an average rectified output current of 1.0A. It includes detailed electrical characteristics like thermal resistance for both glass epoxy and alumina substrates, along with performance graphs for forward current versus voltage and ambient temperature.
Nikon EC10QS06 specifications
| Repetitive Peak Reverse Voltage (VRRM) | 60 V |
|---|---|
| Non-repetitive Peak Reverse Voltage (VrsM) | 65 V |
| Average Rectified Output Current (IRMS) | 1.0 A |
| Surge Forward Current (Irsm) | 20 A |
| Operating Junction Temperature Range | -40 to +150 °C |
| Storage Temperature Range | -40 to +150 °C |
Source: Nihon Inter Electronics EC10QS06 Bridge Rectifier Datasheet
All Nikon EC10QS06 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum repetitive peak reverse voltage for this rectifier?
The device has a maximum repetitive peak reverse voltage rating of 60 V.
From: Nihon Inter Electronics EC10QS06 Bridge Rectifier Datasheet
What is the operating junction temperature range for this component?
The operating junction temperature ranges from -40 to +150 °C.
From: Nihon Inter Electronics EC10QS06 Bridge Rectifier Datasheet
What is the maximum repetitive peak reverse voltage for this device?
The maximum repetitive peak reverse voltage rating is 40 V.
From: nikon inter electronics corporation SBD EC10QS06 datasheet(1)
What is the operating junction temperature range?
The device operates within a junction temperature range of -40 to +150 °C.
From: nikon inter electronics corporation SBD EC10QS06 datasheet(1)
