Start here
Nikon EH-6 AC Adapter User Manual
This manual provides safety precautions, proper handling instructions, and detailed connection steps for the Nikon EH-6 AC adapter used with compatible Nikon digital cameras. It includes warnings about fire, electric shock, and proper use of the power and DC cords.
The document also lists the technical specifications of the adapter, such as input voltage range, output voltage and current, operating temperature, dimensions, cable lengths, and weight, and explains how to attach the supplied cord clips to keep cables organized. This manual is written in Japanese.
Nikon EH-6 specifications
| Input voltage | AC 100‑240 V 50/60 Hz |
|---|---|
| Output voltage / current | DC 13.5 V / 5.0 A |
| Operating temperature | 0 °C – 40 °C |
All Nikon EH-6 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What safety warnings should I follow when using the adapter?
Do not short the DC plug, do not use the adapter with non‑compatible devices, unplug the power cord when not in use, and avoid applying excessive force to the plugs or cables.
How can I keep the AC adapter cable and USB cable from tangling?
Use the two supplied cord clips: place the larger side of the clip on the AC adapter’s DC cord and the smaller side on the USB cable.
What are the electrical specifications of the EH-60 adapter?
The EH‑60 accepts 100–240 V AC at 0.18–0.1 A, 50/60 Hz and provides a 4.2 V DC output at 1.5 A.
Which cameras are compatible with the EH-61 adapter?
The EH-61 is intended for use with Nikon COOLPIX 3100, 2100, and SQ series digital cameras.
What should I do if the POWER lamp does not light?
If the POWER lamp does not light, unplug the AC adapter and take it to an authorized Nikon service center for inspection.
