Start here
Konica Minolta CS-200 Colorimeter Instruction Manual
This document is the user instruction manual for the Konica Minolta CS-200 colorimeter. It provides essential information on safety symbols, warnings regarding electrical usage and battery handling, and environmental conditions required for proper operation.
The manual details the introduction to the device's high-precision measurement capabilities using a new spectral adaptation method. It outlines packaging contents, specific working environment requirements (temperature, humidity, power), and notes on instrument maintenance such as warming up procedures before measuring low luminance objects. This manual is written in Italian.
Konica Minolta CS-200 specifications
| Measurable Range | luminance and chromaticity up to super-low luminance regions |
|---|---|
| Operating Temperature (CS-2000) | 5 and 35°C |
| Operating Temperature (CS-2000A) | 5 and 30°C |
| Relative Humidity | 80% or less |
| Maximum Altitude | 2,000 m |
| Power Supply (AC-A312) | 100 - 120 V ~ or 200 - 240 V ~, 50/60HZz |
Source: Konica Minolta CS-2000/CS-2000A Spectroradiometer Instruction Manual
All Konica Minolta CS-200 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How long does it take to fully charge the backup battery?
The backup battery takes 20 hours to charge completely.
Can the instrument be used outdoors?
No, it should not be used outside because the standard AC adapter is not designed for outdoor use.
What are the operating temperature and humidity limits for the CS-2000?
The CS-2000 must be used at a room temperature between 5°C and 35°C with relative humidity of 80% or less (at 35°C) without condensation.
From: Konica Minolta CS-2000/CS-2000A Spectroradiometer User Manual
What is the warm-up time required for low luminance measurements?
The instrument must be warmed up for at least 20 minutes when measuring objects with luminance of 2 cd/m² or lower at a 1° angle.
From: Konica Minolta CS-2000/CS-2000A Spectroradiometer Instruction Manual
Can the CS-2000 be used outdoors?
No, the standard AC adapter is designed specifically for indoor use and should not be used outdoors.
From: Konica Minolta CS-2000/CS-2000A Spectroradiometer Instruction Manual
What does the prohibition symbol mean?
It indicates an operation that must absolutely not be performed.
From: Konica Minolta CS-200 Spectrophotometer Safety Symbol Manual
