Key facts
- Brand
- AMD
- Model
- Athlon 64
- Category
- Processors
- Documents
- 5
- Languages
- EN · ZH
- Last added
- 2023-10-26
Start here
Socket 754 AMD Athlon 64 / NVIDIA nForce4 SLI/4X Motherboard User Manual
The motherboard supports AMD Socket 754 processors and the NVIDIA nForce4 SLI/4X chipset, offering features such as PCI‑Express, Ultra ATA 100/133, Gigabit LAN, USB 2.0, and 6‑channel audio. It also includes AMD Cool'n'Quiet, NVIDIA ActionArmor, QuickSPDIF, and EZ‑Button utilities for enhanced performance and ease of use.
The guide is organized into chapters covering an introduction, specifications, hardware installation, BIOS setup, RAID configuration, power‑management features, and appendices with BIOS update procedures and RAID BIOS reference. Each section provides step‑by‑step instructions, troubleshooting tables, and configuration tips. This manual is written in Chinese.
AMD Athlon 64 specifications
| CPU Socket | Socket 754 |
|---|---|
| Chipset | NVIDIA nForce4 SLI/4X |
| Audio Channels | 6‑channel (5.1) support |
Source: Socket 754 AMD Athlon 64 / NVIDIA nForce4 SLI/4X Motherboard User Manual
All AMD Athlon 64 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
How to use the product for one specific task, with worked examples.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Which AMD Athlon 64 processors are covered in the February 2007 revision?
The revision was updated for the AMD Athlon 64 FX-62, AMD Athlon 64 FX-70, AMD Athlon 64 FX-72, and AMD Athlon 64 FX-74 dual-core processors.
What benchmarks were removed in the March 2007 revision?
The document removed BAPCO SYSmark 2004 SE Office Productivity, Business Winstone 2004, Worldbench, Remote Collaboration Scenario, Travel-Ready Scenario, BAPCO SYSmark 2004 SE Internet Content Creation, Content Creation Winstone 2004, iTunes Version 6.0.4, Protected High Definition Viewing Scenario, 3DMark 05 Build 1.2.0, City of Villains Version 10.2, Serious Sam II, Half-Life 2 Version 1.0.1.0, Quake 4 Version 1.04, Unreal Tournament 2004 Version 3369, Tom Clancy's Splinter Cell Chaos Theory Version 1.2b, and Far Cry Version 1.3.1.
What performance questions does this document address for AMD Athlon 64 and Opteron systems?
The document addresses where threads or processes should be scheduled and where memory should be allocated.
From: AMD Athlon 64 and Opteron ccNUMA Multiprocessor Systems Performance Guidelines Application Note
What factors influence performance in addition to memory latency and bandwidth?
Performance is also influenced by remote memory access latency, cache coherence maintenance latency, HyperTransport link bandwidth, and buffer queue lengths.
From: AMD Athlon 64 and Opteron ccNUMA Multiprocessor Systems Performance Guidelines Application Note
How can I reset the BIOS settings?
Clear the CMOS using the jumper or by removing the battery to reset the BIOS to its default configuration.
From: Socket 754 AMD Athlon 64 / NVIDIA nForce4 SLI/4X Motherboard User Manual
How do I configure RAID on this motherboard?
Enter the RAID BIOS utility (accessible via the NVIDIA RAID BIOS) and follow the on‑screen prompts to set up the desired RAID mode.
From: Socket 754 AMD Athlon 64 / NVIDIA nForce4 SLI/4X Motherboard User Manual
