Key facts
- Brand
- AMD
- Model
- 133MHz
- Category
- Other device
- Documents
- 7
- Languages
- EN · ZH
- Last added
- 2012-04-05
Start here
AMD Socket A Processor based mainboard(100/133MHz) user manual(3)
This manual covers the AMD 600028A15 Socket A mainboard, detailing its components, system overview, and supported technologies such as DDR‑SDRAM, AGP 2X/4X, and Ultra ATA/66/100. It includes a full parts checklist, layout diagrams, and instructions for CPU installation, jumper settings, and memory configuration.
The guide also explains BIOS setup, advanced chipset features, power‑management options, hardware monitoring, and driver installation. Appendices provide POST code tables, EEPROM BIOS removal procedures, and other technical references to aid both end‑users and service technicians.
AMD 133MHz specifications
| Supported Memory Types | PC1600/PC2100/PC2700 DDR |
|---|---|
| Form Factor | ATX |
| Processor Socket | Socket A (PGA 462) |
| IDE Interface | Ultra ATA/66/100/133 |
Source: AMD Socket A Processor based mainboard(100/133MHz) user manual(5)
All AMD 133MHz documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- AMD Socket A Processor based mainboard(100/133MHz) user manual(5) 86 p
- AMD Socket A Processor Based Mainboard 100/133MHz User Manual 82 p
- AMD Socket A Processor based mainboard(100/133MHz) user manual(3) 88 p
- AMD Socket A Processor based mainboard(100/133MHz) user manual(2) 88 p
- AMD Socket A Processor based mainboard(100/133MHz) user manual(1) 81 p
- AMD Socket A Processor based mainboard(100/133MHz) user manual 80 p
- AMD Socket A 100/133MHz Mainboard User Manual 70 p
Questions answered in these manuals
What do the POST codes FFh and CFh indicate?
They indicate a BIOS chip replacement, a wrong BIOS version, a mainboard problem, or an add‑on card insertion issue.
From: AMD Socket A Processor based mainboard(100/133MHz) user manual(5)
What memory modules are compatible with this mainboard?
The board works with PC1600, PC2100 and PC2700 DDR memory modules.
From: AMD Socket A Processor based mainboard(100/133MHz) user manual(5)
What types of memory can be used with this board?
It accepts PC1600, PC2100, and PC2700 memory modules.
From: AMD Socket A Processor Based Mainboard 100/133MHz User Manual
What form factor does the mainboard use?
The mainboard follows the ATX form factor and requires an ATX 2.01 or later case.
From: AMD Socket A Processor Based Mainboard 100/133MHz User Manual
How can I clear the CMOS?
Clear the CMOS or press the insert key to power on the system.
From: AMD Socket A Processor based mainboard(100/133MHz) user manual(3)
How should the BIOS chip be removed safely?
Only a technician should replace the BIOS chip, using a PLCC IC extractor tool.
From: AMD Socket A Processor based mainboard(100/133MHz) user manual(3)
