Start here
Yamaha CS-10/30/30L Synthesizer Sound Memo Guide
This booklet serves as a companion to the Owner's Manual for the Yamaha CS series of synthesizers. It is designed to help users understand the functions of various controls and levers by demonstrating how to produce specific sounds.
The document provides distinct sound patches tailored for different models: the CS-10 Edition, CS-30 Edition, and CS-30L Edition. Each section includes instructions on adjusting parameters like LFO speed, portamento, and filter cutoff to achieve desired audio effects.
All Yamaha CS-30L documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the purpose of this booklet?
It helps users understand synthesizer functions and how to produce sounds by setting controls as illustrated.
How should I handle patch examples that differ from my image?
You should adjust the controls until you obtain the sound that matches your desired image.
What are the three main elements controlled by a synthesizer?
The synthesizer electrically synthesizes and controls interval, tone, and volume.
What is the maximum voltage that should be applied to the KEY VOLT IN terminal?
You should never apply more than 5V to the KEY VOLT IN terminal.
