Key facts
- Brand
- SONY
- Model
- S270
- Category
- Other Electronics
- Documents
- 3
- Languages
- EN · ZH
- Last added
- 2012-07-09
Start here
Sony HVR-Z1/Z7/A1/V1/S270 User Manual
The manual covers a range of accessories for Sony HVR camcorders, including rechargeable NP‑F970 and NP‑QM81D battery packs, a four‑slot AC charger, soft‑carry case, wide‑angle conversion lens, folding LCD hoods, and remote commanders. Each section describes dimensions, weight, capacity, and usage features such as the Battery Log display and charge‑mode selection.
Additional information includes technical data for the VCT‑PG11RMB fluid head, maximum load limits, and multilingual safety notices. The document is organized by accessory type and provides clear instructions for setup, charging, and handling.
SONY S270 specifications
| NP‑F970 Battery Capacity | 47.5Wh (6600mAh) |
|---|---|
| NP‑F970 Battery Dimensions | 1 9/16 x 2 3/8 x 2 7/8 inches |
| NP‑F970 Battery Weight | 300 g |
| Charger Dimensions | 220 mm × 61 mm × 155 mm |
| Charger Charge Modes | Two (Full / Normal) |
| Soft Carrying Case Dimensions | 25 1/4 × 10 1/4 × 12 1/4 inches |
| Soft Carrying Case Weight | 3400 g |
| LCD Hood Dimensions (3.2") | W 39 × H 60 × D 25 mm |
| VCT‑PG11RMB Maximum Load | 5 kg |
All SONY S270 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the capacity of the NP‑F970 battery pack?
The NP‑F970 battery pack has a capacity of 47.5 Wh (6600 mAh).
How many charge modes does the AC charger provide?
The charger offers two charge modes: Full charge and Normal charge.
What recording formats does the HVR‑Z7C support?
It records in HDV1080/50i, DVCAM and DV SP formats.
From: SONY HDV-Z7C/S270C/M35C high definition digital Videography all-in-one Manual
How long can I record on a PHDVM‑63DM tape?
Up to 63 minutes of recording time.
From: SONY HDV-Z7C/S270C/M35C high definition digital Videography all-in-one Manual
