Start here
Panasonic KX-TDA30/KX-TDA100/KX-TDA200/KX-TDA600 user manual
This user manual provides detailed information on the Panasonic Hybrid IP‑PBX family, covering the KX‑TDA30, KX‑TDA100, KX‑TDA200 and KX‑TDA600 models. It describes the supported telephone types, software requirements, and key features such as IP communication, call centre queuing, voice‑mail integration, and portable stations.
Safety and security sections outline precautions for power failure, water exposure, and data protection, while the index and programming sections guide users through system setup, feature programming, and troubleshooting. The document also lists the network standards each model can interwork with, such as PSTN and ISDN, and provides specifications for optional wireless cell stations. This manual is written in Chinese.
Panasonic KX-TDA600 specifications
| Minimum software version (KX‑TDA30) | 5.0000 or later |
|---|---|
| Minimum software version (KX‑TDA100/200) | 5.0000 or later |
| Minimum software version (KX‑TDA600) | 5.0000 or later |
| Cell Station frequency range (2.4 GHz) | 2401 MHz – 2480 MHz |
| Cell Station output power (2.4 GHz) | 0.004 W – 0.4 W |
| DECT Cell Station frequency range | 1881 MHz – 1898 MHz |
Source: Panasonic KX-TDA30/KX-TDA100/KX-TDA200/KX-TDA600 user manual
All Panasonic KX-TDA600 documents by type
Disassembly, diagnostics and part numbers, for repair.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Instruction set, parameters and examples for configuring or programming the device.
Questions answered in these manuals
What software version is required for the KX‑TDA30 model?
The KX‑TDA30 requires PSMPR software file version 5.0000 or later.
From: Panasonic KX-TDA30/KX-TDA100/KX-TDA200/KX-TDA600 user manual
What are the frequency and power limits for the 2.4 GHz cell station?
It operates between 2401 MHz and 2480 MHz with an output power ranging from 0.004 W to 0.4 W.
From: Panasonic KX-TDA30/KX-TDA100/KX-TDA200/KX-TDA600 user manual
What should you do if the PBX emits smoke or an abnormal smell?
Unplug the PBX from the AC outlet immediately and contact an authorized Panasonic Factory Service Centre.
From: Panasonic KX‑TDA50/KX‑TDA100/KX‑TDA200/KX‑TDA600 PC Programming Manual
How can you confirm the software version of the PBX?
Refer to the FAQ section 2.6.1 titled “How do | confirm the software version of the PBX or installed cards?”.
From: Panasonic KX‑TDA50/KX‑TDA100/KX‑TDA200/KX‑TDA600 PC Programming Manual
What software version is required for the KX‑TDA30?
The KX‑TDA30 requires PSMPR Software File Version 4.0000 or later.
From: Panasonic KX-TDA30/KX-TDA100/KX-TDA200/KX-TDA600 Hybrid IP-PBX PT Programming Manual
Which networks can the KX‑TDA100 interwork with?
It can interwork with Analogue PSTN, ISDN basic rate, ISDN primary rate, and ONP 2048 kbit/s digital structured leased lines.
From: Panasonic KX-TDA30/KX-TDA100/KX-TDA200/KX-TDA600 Hybrid IP-PBX PT Programming Manual
