Key facts
- Brand
- Intel
- Model
- DP43TF
- Category
- Motherboard
- Industry
- Computers
- Documents
- 2
- Languages
- ZH · EN
- Last added
- 2012-04-06
Start here
Intel DP43TF Desktop Motherboard Product Guide
This guide details the functions and features of the Intel DP43TF desktop motherboard, including chipset specifications, supported interfaces, and power management capabilities. It is intended for qualified technical personnel who need to install, configure, and maintain the board.
The document also covers BIOS update procedures, error messages, indicator signals, and regulatory compliance for FCC, CE, and RoHS standards, ensuring safe and reliable operation in home or commercial PC environments. This manual is written in Chinese.
Intel DP43TF specifications
| Chipset | Intel 8 P43 Express |
|---|---|
| USB Support | USB 2.0 |
| PCI Express Slot | PCI Express X16 |
| Memory Type | DDR2 DIMM |
| SATA Interface | Serial ATA (SATA) |
| Power Management | ACPI (Advanced Configuration and Power Interface) |
| Energy Efficiency | Meets ENERGY STAR standard |
All Intel DP43TF documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How can the BIOS be updated on the DP43TF motherboard?
Use the Intel Express BIOS Update utility, the ISO Image BIOS method, or the Iflash Memory Update Utility.
What safety certifications are required for the DP43TF motherboard in the United States?
It must carry NRTL certifications such as UL, CSA, or ETL, and the FCC B‑class EMI certification.
Does the Intel DP43TF desktop board meet FCC compliance requirements?
Yes, the board complies with Part 15 of the FCC Rules as a Class B digital device.
How many USB 2.0 ports does the DP43TF support?
The board supports up to 12 USB 2.0 ports—six on the back panel and six via three internal headers.
