Freescale MC9328MXL Advance Information Datasheet
The MC9328MXL is an advanced, power-efficient ARM920T microprocessor designed for personal and portable products. It features speeds up to 200 MHz and includes highly integrated system functions such as an LCD controller, USB support, and MMC/SD host controllers.
This document provides advance information on the device's functional block diagram, signal descriptions, ordering options including various package types (MAPBGA), and target applications like smart phones and handheld computers.
All Freescale MC9328MXL documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the operating voltage range for the core?
The operating voltage range is 1.7 V to 1.98 V for the core.
What are the available package types?
The device is packaged in either a 256-pin MAPBGA or 225-pin PBGA package.
What operating voltage range does the MC9328MXL core support?
The device operates with a core voltage ranging from 1.7 V to 1.98 V.
What is the maximum operating speed of the MC9328MXL?
The processor operates at speeds up to 200 MHz.
