Start here
freescale MC9S08RC8/16/32/60 MC9S08RD8/16/32/60 MC9S08RE8/16/32/60 MC9S08RG32/60 handbook
This document is a comprehensive data sheet for the Freescale MC9S08RC/RD/RE/RG series of HCS08 microcontrollers. It provides detailed technical information including device pin assignments, modes of operation (Run, Wait, Stop), and memory architecture.
The guide details the specifications for various peripheral modules such as the Central Processor Unit (CPU), Carrier Modulator Timer (CMT), Parallel Input/Output ports, Keyboard Interrupt (KBI), Timer/PWM Module (TPM), Serial Communications Interface (SCI), and Serial Peripheral Interface (SPI). It also includes electrical characteristics and absolute maximum ratings.
Freescale MC32 specifications
| Supply voltage (VDD) | -0.3 to +3.8 V |
|---|---|
| Maximum current into VDD (IDD) | 120 mA |
| Digital input voltage (VIn) | -0.3 to VDD + 0.3 V |
| Storage temperature range (Tstg) | -55 to 150 °C |
Source: freescale MC9S08RC8/16/32/60 MC9S08RD8/16/32/60 MC9S08RE8/16/32/60 MC9S08RG32/60 handbook
All Freescale MC32 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the revision number of this data sheet?
The document is Revision 1.10.
From: freescale MC9S08RC8/16/32/60 MC9S08RD8/16/32/60 MC9S08RE8/16/32/60 MC9S08RG32/60 handbook
When was this data sheet released?
The initial external release was on February 4, 2004.
From: freescale MC9S08RC8/16/32/60 MC9S08RD8/16/32/60 MC9S08RE8/16/32/60 MC9S08RG32/60 handbook
What applications are targeted by the MC9S08AC series?
The series is aimed at general industrial use, motor control, building control, HVAC systems, and home appliances such as dishwashers, washing machines, dryers, and refrigerators.
From: Freescale MC9S08AC60/48/32 8‑bit Microcontroller Datasheet
How many GPIO pins does the MC9S08AC60 provide?
It provides up to 56 programmable GPIO pins.
From: Freescale MC9S08AC60/48/32 8‑bit Microcontroller Datasheet
