Freescale MC9328MX21 Microprocessor Product Preview Datasheet
This document provides a product preview of the Freescale MC9328MX21, part of the i.MX family of microprocessors. It highlights the device's ARM926EJ-S™ core operating at speeds up to 266 MHz and its suitability for portable handheld markets such as smartphones and MP3 players.
The datasheet details key features including optional hardware-enabled security, integrated multimedia accelerators, LCD controllers, USB On-The-Go support, and various connectivity options like WLAN and Bluetooth via PCMCIA/CF interfaces. It also outlines ordering information for different package types and operating temperature ranges.
All Freescale MC9328MX21 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What operating temperature range is available for the MC9328MX21?
The device is available with an operating range from -40°C to 85°C.
From: Freescale MC9328MX21 Microprocessor Product Preview Datasheet
How many pins does the MAPBGA package have?
The MC9328MX21 is packaged in a 289-pin MAPBGA.
From: Freescale MC9328MX21 Microprocessor Product Preview Datasheet
What is the maximum operating speed of the MC9328MX21 microprocessor?
The processor operates at speeds up to 266 MHz.
From: Freescale MC9328MX21 Microprocessor Product Preview Datasheet
What is the physical size of the MAPBGA package for this microprocessor?
The package dimensions are 14mm x 14mm with a lead height of 0.65mm.
From: Freescale MC9328MX21 Microprocessor Product Preview Datasheet
