Start here
TCL TCL-USB (9) User Manual
This manual introduces the TCL-USB (9) VOIP phone, describing its high‑capacity voice processor, USB and PSTN ports, and supported instant‑messaging software. It lists system requirements, package contents, and details the keypad and LCD screen functions.
Installation instructions cover installing Skype, the Skype Phone software, and connecting the device to a computer and PSTN line. The guide also explains how to operate the phone, set parameters, view call logs, and perform maintenance and troubleshooting.
TCL USB(9) specifications
| CPU requirement | Pentium 586 or above |
|---|---|
| Memory requirement | More than 64 M |
| Supported operating systems | Windows 2000 / Windows XP / Mac OS 9 / Mac OS X |
| USB port support | USB 1.1 / USB 2.0 |
| Power source | Standard USB port power, no external supply needed |
Source: TCL TCL-USB (9) User Manual
All TCL USB(9) documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I dial a PSTN phone with the TCL‑USB (9)?
Use the PSTN port on the device to dial normal telephone numbers, which allows emergency calls and works when the network is jammed.
How can I view the calling time of dialed calls?
Press the OUT/Y key first, then press CID/A or OUT/V to display the call duration on the LCD screen.
How can I mute a Skype call?
Press the MUTE key during a Skype call; the LCD displays a mute icon and the remote party cannot hear you.
What are the system requirements for the telephone?
A CPU of 586 or higher, at least 64 M of memory, Windows 2000/XP or Mac OS 9/OS X, and a USB 1.1 or USB 2.0 port.
