TCL HiD4321H/HiD5221H Television User Manual
The guide begins with safety warnings and installation instructions for the projection TV, including handling of high‑voltage components, proper placement, ventilation, and securing the mobile wheels. It also details how to connect external devices such as DVD players, set‑top boxes, and computers.
Subsequent sections cover remote‑control functions, color‑center adjustment, picture‑in‑picture operation, audio and video settings, and a troubleshooting chapter that helps resolve common image or sound issues. Technical specifications of the TV are listed at the end of the document. This manual is written in Chinese.
TCL HID432 specifications
| Screen size (HID432) | 109 cm (43 in) diagonal |
|---|---|
| Screen size (HID522) | 132 cm (52 in) diagonal |
| Power consumption | 200 W |
| Input voltage | 175 V‑240 V, 50‑60 Hz |
| Dimensions (HID522) | 1124 mm × 530 mm × 1375 mm |
| Weight (HID522) | 66 kg |
| Supported AV formats | PAL, NTSC 3.58, NTSC 4.43 |
| VGA input resolution | 640 × 480 @ 60 Hz |
All TCL HID432 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What screen size does the HID432 model have?
The HID432 has a 109 cm (43 in) diagonal screen.
How much power does the TV consume?
The television consumes 200 W of power.
How do I replace the batteries in the remote control?
Open the battery compartment on the back of the remote, insert two 7‑mm 1.5 V batteries with the correct polarity, and close the cover.
How is the color‑center adjustment performed?
Press the MENU key, select the red/blue convergence adjustment, use the remote to fine‑tune until the convergence point turns white, then store the settings with the ANIMATION key.
What is the standby power consumption of the TV?
The standby power consumption is 3 W.
What screen sizes are available for the HID4321HB and HID5221HB models?
The HID4321HB has a 43‑inch (109 cm) screen, while the HID5221HB has a 52‑inch (132 cm) screen.
