Key facts
- Brand
- Siemens
- Model
- MICROMASTER430
- Documents
- 9
- Languages
- ZH · EN
- Last added
- 2026-10-17
Start here
MICROMASTER 430 General-Purpose Inverter 7.5kW-250kW User Guide
The document serves as a comprehensive user guide for the Siemens MICROMASTER 430 general-purpose inverter, covering power ratings from 7.5kW to 250kW. It provides detailed instructions on installation and commissioning using SDP (Software Development Platform) and BOP-2 (Basic Operator Panel). The guide explains control methods, system parameter structures, troubleshooting procedures, technical specifications, and lists available optional parts. This manual is written in Chinese.
Read onlineSiemens MICROMASTER430 specifications
| Power Rating | 7.5 kW - 250 kW |
|---|---|
| Software Version | V2.1 |
| Order Number | 6SE6400-5AE00-0MP0 |
All Siemens MICROMASTER430 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Siemens MICROMASTER 430 7.5-250 kW User Manual 113 p
- Siemens MICROMASTER 430 Variable Frequency Drive User Manual 113 p
- MICROMASTER 430 General-Purpose Inverter 7.5kW-250kW User Guide 369 p
- Siemens Micromaster 430 Parameter List 202 p
- SIEMENS MICROMASTER 430 7.5 kW - 250 kW Manual 134 p
- Siemens Micromaster 420/430/440 User Manual 99 p
- SIEMENS MicroMaster430 general frequency transformer Manual
- Siemens MICROMASTER 430 Simple Debugging Guide 28 p
- Siemens MicroMaster 430 Variable Frequency Drive User Manual 28 p
Questions answered in these manuals
Who is authorized to operate this device?
Only qualified professional personnel who have received specific training and passed examinations are allowed to operate the device.
What safety precautions are required before opening the device?
The device must be disconnected from the power supply and allowed to stand for 5 minutes to discharge capacitors before opening.
What is the input voltage range for the MICROMASTER 430?
The drive operates on an AC input voltage of 380 V to 480 V with a tolerance of ±10 %.
From: Siemens MICROMASTER 430 Variable Frequency Drive User Manual
What output frequency can the MICROMASTER 430 provide?
It can generate an output frequency from 0 Hz up to 650 Hz.
From: Siemens MICROMASTER 430 Variable Frequency Drive User Manual
What software version is covered in this manual?
This manual covers the MICROMASTER 430 V2.0 software version.
From: MICROMASTER 430 General-Purpose Inverter 7.5kW-250kW User Guide
Which power ratings are included in this guide?
The guide is applicable for inverters ranging from 7.5kW to 250kW.
From: MICROMASTER 430 General-Purpose Inverter 7.5kW-250kW User Guide
