Key facts
- Brand
- Lincoln Electric
- Model
- 220TPX
- Category
- Other
- Industry
- Industrial
- Documents
- 6
- Languages
- FR · EN · PT
- Last added
- 2023-10-15
Start here
Lincoln Electric INVERTEC 170TX/TPX & 220TPX Inverter Welders User Manual
This document is the Portuguese user manual for the Lincoln Electric INVERTEC 170TX/TPX and 220TPX inverter welders. It provides instructions for installation, operation, and maintenance, along with technical specifications for various models and regional configurations (CE and AUS). The manual includes safety guidelines, electromagnetic compatibility (EMC) information, and details on spare parts and recycling. This manual is written in Portuguese.
Read onlineAll Lincoln Electric 220TPX documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX User Manual 25 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual 25 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual 23 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX User Manual 23 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual 23 p
- Lincoln Electric INVERTEC 170TX/TPX & 220TPX Inverter Welders User Manual 28 p
Questions answered in these manuals
What is the input voltage for the INVERTEC 170TX CE model?
The input voltage is 230Vac + 15%.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual
What is the maximum output current for the INVERTEC 170TPX AUS model?
The maximum output current is 170A.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual
What is the open circuit voltage for the INVERTEC 220TPX CE model?
The open circuit voltage is 63 Vdc.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual
What is the recommended fuse size for the INVERTEC 170TX/170TPX AUS model?
A 16A time delayed fuse or circuit breaker is recommended.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual
Is the INVERTEC 220TPX suitable for residential use?
No, the Class A equipment is not intended for use in residential locations where power is provided by the public low-voltage supply system.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual
How should the equipment be disposed of at the end of its life?
The equipment must be recycled separately from household waste according to the WEEE Directive.
From: Lincoln Electric INVERTEC 170TX/TPX & 220TPX Inverter Welders User Manual
