Key facts
- Brand
- Lincoln Electric
- Model
- 165S
- Documents
- 3
- Languages
- EN
- Last added
- 2026-10-27
Start here
Lincoln Electric INVERTEC 165S Operator's Manual
The document serves as an operator's guide for the INVERTEC 165S, a single-phase supply welding unit. It includes technical specifications such as a maximum consumption of 34.4 A and a duty cycle of 20% at 160 A.
Read onlineLincoln Electric 165S specifications
| Rated Output | 160A@20% 100A@60% 80A@100% |
|---|---|
| Dimensions HxWxD | 265 x 162 x 385 mm |
| Protection Class | IP23 |
Source: Lincoln Electric Invertec 165S & 165SX Inverter Welder Product Leaflet
All Lincoln Electric 165S documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What welding processes does the Invertec 165S support?
The Invertec 165S supports Stick and TIG Scratch welding.
From: Lincoln Electric Invertec 165S & 165SX Inverter Welder Product Leaflet
What is the weight of the Invertec welders?
The units are lightweight, weighing less than 9 kg (7 kg for 165S and 8.2 kg for 165SX).
From: Lincoln Electric Invertec 165S & 165SX Inverter Welder Product Leaflet
Who is authorized to operate this welding machine?
This equipment must be used by qualified personnel.
From: Lincoln Electric 165S Welding Machine Operator's Manual
What is the maximum incline for equipment stability?
The stability of the equipment is guaranteed only for an incline of maximum 10°.
From: Lincoln Electric 165S Welding Machine Operator's Manual
What is the maximum welding current?
The machine supports a welding current range of 5 A to 160 A.
What is the duty cycle at maximum current?
The duty cycle is 20% when operating at 160 A.
