Key facts
- Brand
- Lincoln Electric
- Model
- 170TX
- Industry
- Industrial
- Documents
- 7
- Languages
- FR · EN · RO · PT
- Last added
- 2023-10-15
Start here
Lincoln Electric Invertec 170TX/TPX and 220TPX User Manual
This document is the Romanian user manual (Manual de Utilizare) for the Lincoln Electric Invertec 170TX, 170TPX, and 220TPX series of inverter welding machines. It covers technical specifications for both CE and Australian models, including input/output ratings, dimensions, and environmental conditions.
Read onlineAll Lincoln Electric 170TX documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX User Manual 25 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual 25 p
- Lincoln Electric Invertec 170TX/TPX and 220TPX User Manual 28 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual 23 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX User Manual 23 p
- Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual 23 p
- Lincoln Electric INVERTEC 170TX/TPX & 220TPX Inverter Welders User Manual 28 p
Questions answered in these manuals
What is the input voltage for the INVERTEC 170TX CE model?
The input voltage is 230Vac + 15%.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual
What is the maximum output current for the INVERTEC 170TPX AUS model?
The maximum output current is 170A.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual
What is the input voltage for the CE model?
The input voltage for the CE model is 230 Vca ± 15% at 50/60 Hz.
From: Lincoln Electric Invertec 170TX/TPX and 220TPX User Manual
What is the input voltage for the Australian model?
The input voltage for the Australian model is 240 VCA ± 15% at 50/60 Hz.
From: Lincoln Electric Invertec 170TX/TPX and 220TPX User Manual
What is the open circuit voltage for the INVERTEC 220TPX CE model?
The open circuit voltage is 63 Vdc.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual
What is the recommended fuse size for the INVERTEC 170TX/170TPX AUS model?
A 16A time delayed fuse or circuit breaker is recommended.
From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual
