Lincoln Electric 170TPX Manuals

ManualLib has 5 documents for the Lincoln Electric 170TPX: 5 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 5

Key facts

Model
170TPX
Industry
Industrial
Documents
5
Languages
FR · EN · PT
Last added
2023-10-15

Start here

Lincoln Electric INVERTEC 170TX/170TPX/220TPX User Manual

Lincoln Electric INVERTEC 170TX/170TPX/220TPX User Manual

User Manual 25 pages · 2.9 MB · FR

This document is the French user manual for the INVERTEC 170TX, 170TPX, and 220TPX welding power sources manufactured by Lincoln Electric. It includes compliance declarations, technical specifications for different models and regions (CE/AUS), and guidelines for electromagnetic compatibility. This manual is written in French.

Read online

All Lincoln Electric 170TPX documents by type

User Manual 5

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the input voltage for the INVERTEC 170TX CE model?

The input voltage is 230Vac + 15%.

From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual

What is the maximum output current for the INVERTEC 170TPX AUS model?

The maximum output current is 170A.

From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual

What is the open circuit voltage for the INVERTEC 220TPX CE model?

The open circuit voltage is 63 Vdc.

From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual

What is the recommended fuse size for the INVERTEC 170TX/170TPX AUS model?

A 16A time delayed fuse or circuit breaker is recommended.

From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Welding Machine Operator's Manual

Is the INVERTEC 220TPX suitable for residential use?

No, the Class A equipment is not intended for use in residential locations where power is provided by the public low-voltage supply system.

From: Lincoln Electric INVERTEC 170TX/170TPX/220TPX Operator's Manual
