Epson RC+ 7.0 Manuals

ManualLib has 8 documents for the Epson RC+ 7.0 (Industrial Robot): 2 service manuals, 4 user manuals, 2 programming manuals. Every file can be read online or downloaded as a PDF for free.

Service Manual 2User Manual 4Programming Manual 2

Key facts

Brand
Epson
Model
RC+ 7.0
Industry
Industrial
Documents
8
Languages
ES · ZH · EN
Last added
2026-10-27

Start here

Epson RC+ 7.0 User Guide

Epson RC+ 7.0 User Guide

User Manual 508 pages · 11.8 MB · ZH

This guide introduces the Epson RC+ 7.0 robot system, covering safety requirements, warranty information, and general usage guidelines. It explains the responsibilities of the user, the conditions that void the warranty, and the necessary precautions when operating the robot.

The manual details hardware and software installation, system startup, communication methods, GUI functions, and programming basics. Appendices describe software installation steps, patch updates, and system requirements for the simulator, helping users set up and maintain the robot efficiently. This manual is written in Chinese.

Read online

Epson RC+ 7.0 specifications

Power Voltage24V DC, 5%
Rated Current2A or less
Operating Temperature5 to 40 degrees Celsius
Operating Humidity20% to 80% (no condensation)
Weight1.5 kg

Source: Epson RC+ 7.0 Vision Guide 7.0 Hardware and Setup Manual

All Epson RC+ 7.0 documents by type

Service Manual 2

Disassembly, diagnostics and part numbers, for repair.

User Manual 4

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Programming Manual 2

Instruction set, parameters and examples for configuring or programming the device.

Questions answered in these manuals

Which robot series are covered by this manual?

This manual covers the T series (T3, T6) and the VT series (VT6) robot systems.

From: Epson RC+ 7.0 Security and Installation Manual for T, VT Series

What are the conditions for warranty repair?

Products will be repaired free of charge during the normal warranty period if they malfunction due to normal handling or operation.

From: Epson RC+ 7.0 Security and Installation Manual for T, VT Series

What is the rated operating temperature range for the CV1?

The unit is rated for an ambient temperature range of 5 to 40 degrees Celsius.

From: Epson RC+ 7.0 Vision Guide 7.0 Hardware and Setup Manual

What is the maximum rated current for the CV1 power supply?

The rated current is 2 amperes or less.

From: Epson RC+ 7.0 Vision Guide 7.0 Hardware and Setup Manual

What operating systems are supported by the RC+ API?

The manual supports Microsoft Windows XP, Vista, 7, 8, and 10.

From: Epson RC+ 7.0 Option RC+ API 7.0 Programming Manual

Can multiple robot controllers be controlled from one PC?

Yes, the manual provides instructions and sample programs for controlling multiple controllers from a single PC.

From: Epson RC+ 7.0 Option RC+ API 7.0 Programming Manual
