A7S266-VM/U2 is a motherboard produced by ASUS. It supports Socket 462 AMD™ CPU, memory types are 184-Pin DDR DIMM Sockets, 168-Pin SDR DIMM Sockets, supports USB 2.0, IDE, FDD, PS/2 and other interfaces.
This manual covers all essential information for installing and configuring the ASUS A7S266-VM/U2 motherboard. It begins with safety precautions, explains jumper settings, and details the physical layout of the board. Subsequent sections guide users through BIOS updates, advanced menu options, power management, and the use of supplied utilities.
Additional resources such as ASUS support contacts, online update tools, and driver installation instructions are provided at the end of the document, helping users keep the motherboard firmware and software up to date.
Before installation, disconnect power, ground yourself, verify all power cables are correctly connected, and consider professional assistance for grounding and handling.
Place a jumper cap on the appropriate pins (e.g., pins 1‑2 for Jumper Mode, pins 2‑3 for Jumper Free) as illustrated in the jumper settings diagram.
