ASRock 775Twins‑HDTV Motherboard Quick Installation Guide
This guide provides an overview of the ASRock 775Twins‑HDTV motherboard, its components, and the required accessories. It includes a detailed parts list, motherboard layout diagram, and key specifications such as form factor, chipset, memory support, and I/O ports.
The document walks the user through pre‑installation precautions, CPU installation, SATA and RAID setup, BIOS configuration, and driver installation. Safety warnings, static‑discharge recommendations, and troubleshooting tips are also included to help ensure a successful build.
ASRock 775TWINS-HDTV specifications
| Form Factor | Micro ATX 9.6" x 9.6" (24.4 cm x 24.4 cm) |
|---|---|
| CPU Socket | LGA 775 (775‑Pin) supporting Intel Dual Core Pentium, Pentium D, Pentium 4, Celeron D |
| Front Side Bus | 1066/800/533 MHz |
| Chipset | Northbridge: ATI Radeon Xpress 200; Southbridge: ULi 1573 |
| Memory Slots | 2× DDR (max 4 GB) and 2× DDR2 (max 4 GB) |
| Expansion Slots | 2× PCI, 1× PCI‑Express x16, 1× PCI‑Express x1, 1× AMR |
| Integrated Graphics | ATI Radeon X300, DirectX 9.0, Pixel Shader 2.0, up to 128 MB shared memory |
| Audio Codec | Realtek ALC850 7.1‑channel AC’97 |
| LAN | Realtek RTL8201CL 10/100 Mb Ethernet, Wake‑On‑LAN |
Source: ASRock 775Twins‑HDTV User Manual
