The RTR025N05 is a N-channel MOSFET from ROHM. It has a low on-resistance, built-in G-S protection diode and a small surface mount package.
The RTRO25N05 is a 2.5 V drive N‑channel MOSFET offered by ROHM. The datasheet provides the device structure, key features such as low on‑resistance and an integrated protection diode, and typical application uses for switching circuits.
Technical information includes absolute maximum ratings, electrical characteristics, thermal data, packaging details, and measurement circuit diagrams to aid designers in implementing the component safely and efficiently.
| Drain‑Source Voltage (VDS) | 45 V |
|---|---|
| Gate‑Source Voltage (VGS) | 12 V |
| Continuous Drain Current (ID) | 42.5 A |
| Pulsed Drain Current (ID,pulse) | 10 A |
| Continuous Source Current (IS) | 0.8 A |
| Total Power Dissipation (PD) | 1.0 W |
| Maximum Junction Temperature (Tj) | 150 °C |
| Storage Temperature Range | -55 °C to +150 °C |
| Thermal Resistance (RθJA) | 125 °C/W |
| Body Diode Forward Voltage (VF) at 2.5 A | 1.2 V |
The device can tolerate up to 45 V between drain and source.
It is rated for a continuous drain current of 42.5 A.
Yes, it has a built‑in gate‑source protection diode.
